PK 1050 TEC

HYDRAULIC & TECHNICS

• 8 hydraulic boom extensions (G)
• High-speed boom extension system with return oil recovery
• Swivel range endless
• Hydraulic support leg extension (max.support width 8.800mm)
• Support legs can be swiveled hydraulically through 180°
• Additional hydraulic support stabilizers
• Hose equipment for two additional devices including quick coupling (multi-faster)
• 3,5to cable winch on the main arm (hydr. foldable)
• Rope length: 90m


ASSISTANCE SYSTEMS

• Paltronic 180
• HPSC + LOAD
• Remote controlled stabilizers
• CPS (cabin protection)
• FPS (Frame Protection System)
• P-FOLD (Folding Assistant)
• Weigh function
• AOS (Active Oscillation Suppression)
• SRC (Synchronised Rope Control)
• RTC (Rope Tension Control)


EQUIPMENT

• Palfinger P6 radio remote control /9 functions with cross levers
• lightning package LEDPACK & VISION
• two Premium working lights on the articulated arm
• Multifunctional adapter for equipment
• 11,5to load hook
• 2 strand rope equipment on the Crane
• Painting RAL3020
• hydraulic oil tank 400 l

• 6 hydraulic extensions (E)
• High-speed extension system with return oil recovery
• Hydr. tiltable upwards by 25°
• 1 strand rope equipment for the PJ 190
• two Premium working lights at the PJ 190
• PJMFA - Multifunctional adapter
• Hose equipment for two additional devices including quick coupling (multi-faster)

• Palfinger MCC low built platform
• Platform inner dimensions: 5.400mm x 2.480mm
• Front wall: height 1.400mm
• Side- and rearwalls height: 400mm
• Platform floor 27 mm plywood, impregnated and sealed
• Various lashing options on the platform floor
• Loading height: 1.180 mm
• 1 pair of Container locks
• 6 working lights
• 2 reversing lights
• Rear view camera
• Two-part telescopic ladder
• Trailer coupling: ROCKINGER Typ 400 G 150A
• 2 wheel chocks

• Engine: 520 Hp, torque max. 2.650 Nm
• Gearbox: MAN TipMatic 12.28 OD
• MAN pritarder with MAN EVBec high-performance engine brake
• 20to front frame reinforcement
• Heavy-duty roll stabilisation for rear axle
• Axle distance: 1.795mm + 3.505mm + 1.350mm
• leaf suspension on front axles / leaf suspension on rear axles
• Fuel tank 390l / AD-Blue 35l
• Tires 1st, 2nd & 4th axle: 385/65R22.5
• Tires driven axle: 315/80 R22.5
• Rims on all axles: aluminium Alcoa Durabright
• Tire pressure and heat monitoring system
• Cabin colour: RAL 9016 / chassis colour: RAL9011
• Cabin type: TM
• Premium Cabin interior
• auxiliary heating: 4 kW
• Multifunctional steering wheel
• Infotainment system equipped with 12,3-inch colour display
• GSR II options included
• construction Year: 2026
