P 300 KS

• Working height approx. 30.00 m
• Cage floor height approx. 28.00 m
• Maximum outreach approx. 20.50 m
• Range of swivel table max. 540°
• Counter slewing system with two slewing rings rotating in opposite directions
• Slewing within the vehicle width
• Swivel range of cage boom 190°
• Rotation range of workman cage approx. +/- 85°
• Permissible inclination max. 5°
• Reduction in reach from 0.5°

• High rigidity and stability thanks to multi-folded, high-strength fine-grained steel in each telescopic section
• Cage load sensor
• Device movements shut off when the basket touches the ground
• Covers made of aluminum chequer plate
• Fully variable outrigger system with ground pressure monitoring
• Outrigger controls on the left and right of the base and in the workman cage
• Automatic deployment with vehicle tilt monitoring
• Can be operated without outriggers
• Engine start-stop function in the workman cage and at the base
• Modern, modular cage control panel with colour graphic display and robust cover
• Display showing possible directions of movement
• Display showing operating instructions
• Main movements continuously adjustable via two joysticks, up to 4 movements simultaneously
• Membrane keys easy to clean
• Home function in the workman cage and at the base
• Continuously variable proportional control
• Automatic cage arm assist function
• Sensitive cage levelling
• Hydraulic cage rotation mechanism with automatic centre position
• Voltage monitoring of the vehicle battery
• Earthing connections on the base frame and boom system
• Inspection log and operating instructions
• CE mark
• EC Declaration of Conformity

*The figures given above are standard values and may vary depending on the equipment and base vehicle
