PK 1350 TEC

HYDRAULICS & TECHNICS

• 9 hydraulic boom extensions (H)
• High-speed boom extension system with return oil recovery
• Swivel range endless
• Hydraulic support leg extension (max.support width 10.000mm)
• Support legs can be swiveled hydraulically through 180°
• Additional hydraulic support (support width ca. 8.500 mm)
• Hose equipment for two additional devices including quick coupling (multi-faster)
• 3,5to cable winch on the main arm (hydr. foldable)
• Rope length: 90m
• Preparation for EN280 operation

ASSISTANCE SYSTEMS

• Paltronic 180
• HPSC + LOAD
• Remote controlled stabilizers
• CPS (cabin protection)
• FPS (Frame Protection System)
• P-FOLD (Folding Assistant)
• AOS (Active Oscillation Suppression)
• SRC (Synchronised Rope Control)
• RTC (Rope Tension Control)


EQUIPMENT

• Palfinger P6 radio remote control /9 functions with cross levers
• lightning package LEDPACK & VISION
• two Premium working lights on the articulated arm
• Multifunctional adapter for equipment
• 2 strand rope equipment on the Crane
• 11,5to load hook
• Painting RAL3020
• hydraulic oil tank 400 l

• 6 hydraulic extensions (E)
• High-speed extension system with return oil recovery
• Hydr. tiltable upwards by 25°
• MFA-L - Multifunctional adapter
• 1 strand rope equipment for the PJ 190
• two Premium working lights at the PJ 190
• Hose equipment for two additional devices

• Palfinger MCC low built platform
• Platform inner dimenstions: 4.350 mm x 2.480 mm
• Front wall: height 1.400 mm including 2 working lights, 2 lashing rings & a bracket for chains and loops
• Side- and rearwalls height: 400 mm
• rear wall includes 2 extendable brackets for horizontal rear wall positioning
• Platform floor 27 mm plywood
• step up ladder integrated into the platform floor
• 1 pair of rigid containerlocks (positioned behind frontwall)
• 4 pairs of 5t lashing rings in the surrounding profile
• Loading height: 1.170 mm
• 6 working lights (4x at stabilizers & 2x at frontwall)
• 4 reversing lights
• Rear view camera
• Emergency power pack for EN280 basket operation
• Heavy duty tool box with a load capacity of 500 kg
• 2 pcs. of heavy duty chain-trays at the additional stabilizers
• Trailer coupling: ROCKINGER Typ 400 G 150A
• 2 wheel chocks

• Engine: 540 Hp, torque max. 2.650 Nm
• Gearbox: MAN TipMatic 12.28 OD
• MAN pritarder with MAN EVBec high-performance engine brake
• 20to front frame reinforcement
• Heavy-duty roll stabilisation for rear axle
• Axle distance: 1.795mm + 2.980mm + 1.350mm
• leaf suspension on front axles / leaf suspension on rear axles
• Fuel tank 390l / AD-Blue 35l
• Tires 1st, 2nd & 4th axle: 385/65R22.5
• Tires driven axle: 315/80 R22.5
• Rims on all axles: aluminium Alcoa Durabright
• Tire pressure and heat monitoring system
• Cabin colour: RAL 9016 / chassis colour: RAL9011
• Cabin type: TM
• Premium Cabin interior
• auxiliary heating: 4 kW
• Multifunctional steering wheel
• Infotainment system equipped with 12,3-inch colour display
• GSR II options included
• construction Year: 2026
