PK 1050 TEC

HYDRAULIC & TECHNICS

• 8 hydraulic boom extensions (G)
• High-speed boom extension system with return oil recovery
• Swivel range endless
• Hydraulic support leg extension (max.support width 8.800mm)
• Support legs can be swiveled hydraulically through 180°
• Additional hydraulic support stabilizers
• Hose equipment for two additional devices including quick coupling (multi-faster)
• 3,5to cable winch on the main arm (hydr. foldable)
• Rope length: 90m


ASSISTANCE SYSTEMS

• Paltronic 180
• HPSC + LOAD
• Remote controlled stabilizers
• CPS (cabin protection)
• FPS (Frame Protection System)
• P-FOLD (Folding Assistant)
• Weigh function
• AOS (Active Oscillation Suppression)
• SRC (Synchronised Rope Control)
• RTC (Rope Tension Control)


EQUIPMENT

• Palfinger P6 radio remote control /8 functions with linear levers
• LED - working lights on the articulated arm
• 11,5to & 18,0to load hook
• 2 strand rope equipment on the Crane
• MFA-L (multifunctional adapter)
• Painting RAL3020
• hydraulic oil tank 400 l

• Hydraulischer 6-fach Ausschub (E)
• Schnellgängiges Ausschubsystem mit Rückölverwertung
• Zusätzlicher Arbeitsbereich durch 25° Überstreckung
• MFA-L (Multifunktionsadapter)
• 1-strängiges Seilwindenzubehör am PJ 190
• inkl. Premium- Arbeitsscheinwerfer

• Platform inner dimensions: 4.800 mm x 2.480 mm
• Front wall: height 1.400 mm
• Side- and rearwalls height: 400 mm
• Platform floor 27 mm plywood, impregnated and sealed
• Various lashing options on the platform floor
• Loading height: 1.180 mm
• 1 pair of Container locks
• 6 working lights
• 2 reversing lights
• Rear view camera
• Two-part telescopic ladder
• Trailer coupling: RF40 G 150 A
• 2 wheel chocks

• Engine: 560 Hp, torque max. 2.800 Nm
• Gearbox: G33CM + Opticruise + retarder
• Axle distance: 1.990mm 2.960mm + 1.350mm
• air suspension on all axles
• Fuel tank 395l / AD-Blue 80l
• Tires 1st & 2nd axle: 385/65 R22.5
• Tires driven axles: 315/80 R22.5
• Rims on all axles: aluminium Alcoa DuraBright
• Cabin colour: Scania Ivory White / chassis colour: Scania Sub Grey
• Cabin type: CR20N
• Premium Cabin interior
• auxiliary heating: 3kW
• Multifunctional steering wheel
• Infotainment system equipped with 10.1-inch colour display
• GSR II options included
