Liftgates
Key Specs
Imperial
Metric
Weight Capacity
Up to 1497 kg Up to 3300 lbs.
Platform Size
Up to 1524 mm x 2032 mm Up to 60"x80"
Bed Height
Up to 1397 mm Up to 55"

The ILP Pallet Pro provides significant value at a small premium. The different capacities, arms, and platform sizes offer a full mounting range from Low Pro chassis to full-size trucks.

Find Sales Partner

Request a quote

I agree that my data will be stored to fulfill my request in the systems of the PALFINGER Group. This data is stored for documentation purposes for three years. *

I agree that PALFINGER may store my data beyond this inquiry and send me further information, highlights and offers for marketing purposes.

Request a quote

I agree that my data will be stored to fulfill my request in the systems of the PALFINGER Group. This data is stored for documentation purposes for three years. *

I agree that PALFINGER may store my data beyond this inquiry and send me further information, highlights and offers for marketing purposes.

Protected Power, Ready to Perform

The thermo-protected power pack is fully enclosed in the mount tube for added protection and slides out for quick inspection. Oversized, high-quality components reduce maintenance and downtime, ensuring reliable liftgate performance in demanding conditions and extreme temperatures.



alt text

Smooth Operation & Built-In Safety

ILP’s dual torsion springs, adjustable rollers, and leveling joint ensure smooth, ground-clear performance. The mid-arm, two-cylinder design offers maximum stability with minimal weight. A fixed receiver hitch and other options are available, plus aerospace-grade hydraulic fluid and a cylinder lock for added control and safety.

Technical Specifications

Technical data U.S. Units

Lifting capacity (lbs)

Approx. weight (lbs)

Bed height range (inch)

Platform size length (inch)

Platform size width (inch)
ILP 25 2,500 lbs 750-850 lbs. 38-55" Available in 48" | 54" | 60" lengths 80"
ILP 33 3,300 lbs 840-930 lbs. 38-55" Available in 48" | 54" | 60" lengths 80"
Technical data metric

Lifting capacity

Approx. weight

Bed height range

Platform size length

Platform size width

ILP 25 1,133 kg 340-385 kgs. 965-1397 mm Available in 1219 mm | 1371 mm | 1524 mm lengths 2032 mm
ILP 33 1,496 kg 381-421 kgs. 965-1397 mm Available in 1219 mm | 1371 mm | 1524 mm lengths 2032 mm
Standard features





Discover Standard Features

Bushings & Zerks at All Pivot Points

Bushings and grease zerks at all pivot points ensure smoother operation and extended component life. Designed for durability and easy maintenance, this setup minimizes wear and reduces service intervals—ideal for fleets seeking long-term reliability and performance.

alt text
Galvanized

PALFINGER offers galvanized finishes in multiple combinations to suit your climate and operational needs. Engineered for superior corrosion resistance, this durable coating protects against rust and harsh conditions—ideal for demanding environments and long-term performance.

alt text

Optional Features

Extra Heavy-duty Trailer Dock Bumpers

PALFINGER’s extra heavy-duty trailer dock bumpers are built to absorb impact, protect your liftgate, and extend trailer life. Engineered for rugged performance in high-traffic loading zones, they reduce wear and damage—delivering long-term value and reliability for demanding fleet operations.

Cart Stops

Secure cargo and prevent roll-off with heavy-duty cart stops—designed for liftgate-equipped service trucks. Built to withstand tough jobsite conditions, they offer reliable load control during loading and unloading. Easy to use, durable, and essential for safe, efficient operations.

DOT-Compliant Rear Impact Guard

PALFINGER’s DOT-compliant rear impact guard is built for safety and strength. Engineered to meet federal standards, it protects against rear-end collisions while enhancing trailer durability. Ideal for fleets focused on safety, compliance, and long-term performance.

Handheld Remote

Control liftgate functions with ease using our handheld remote—designed for durability, precision, and convenience. Whether you're loading or unloading, enjoy smooth, responsive operation right at your fingertips. Built for tough environments and reliable performance.

Aluminum Platforms

Boost load capacity and durability with aluminum platforms—lightweight, corrosion-resistant, and built to perform. Ideal for delivery fleets and commercial vehicles.

Wireless Remote

Wireless remote controls offer fast, reliable liftgate operation with enhanced safety and flexibility. Operators can manage lift functions, improving workflow —perfect for busy delivery environments and efficient fleet performance.

Rubber Pads

Protect your liftgate and cargo with durable rubber pads on the dock bumpers —designed to absorb impact, reduce wear, and improve grip during loading and unloading. Ideal for high-traffic fleets, these pads extend equipment life and enhance safety in every delivery. A simple upgrade with lasting benefits.

2" Receiver Hitch

Add towing versatility with a 2" receiver hitch—perfect for attaching cargo carriers, bike racks, or trailers. Built for strength and compatibility, it enhances your liftgate’s utility while maintaining safety and performance. A smart upgrade for fleet flexibility.
