P 170 TXE-E SMART PLUS
Iveco DAILY 35 EURO 6 E
- Location
- via Enrico de Nicola, IT, 41122
- Dealer
- Palfinger srl
- Product Type
- New
- Multifunction electric controls for greater precision, speed, and manoeuvring comfort
- Vertical stabilisation with frontwards extending outriggers which compensate for uneven and sloping ground
- Platform with three stabilisation possibilities for each working condition:
- Within the outer vehicle limits: for maximum compactness overall within small spaces
- With front outriggers extended: for maximum performance when working in elevated positions
- Partial stabilisation: for maximum performance with minimum overall dimensions.
- 12V socket on basket
- 230 V/16 socket A or 110V/16A 12V socket on basket
- Aerial section centring display for aerial part closing
- Air/water line from the column to the basket
- Anti-collision system cab/boom
- Painting with cataphoresis process, with KTL system patented by PALFINGER
- 4 spreader plates with proper housing on the chassis
- Top boom protection
- Electric hour meter
- Cage rotation 90°+ 90°
- Inclinometer with audio alarm signal and signal lights relating to aerial work conditions
- Preparation for insulation upgrade ability
Technical Specifications
Product
- Manufacturer
- PALFINGER
- Model
- P 170 TXE-E SMART PLUS
- Outreach
- 11,80 m
- Max. height of work
- 16,9 m
- Turret rotation
- 370°
- Basket size
- 1,4x0,84x1,1 m
- Basket capacity
- 250 kg
- Basket turning device
- 90°+90°
- Basket material
- alu
Truck
- Truck manufacturer
- IVECO
- Wheel base
- 3750 mm
- Emmission standard
- EURO 6 E
- Axes
- 4x2
- Gross vehicle weight
- 3,5 TON
