Heavy

PK 44502 High Performance

Loader Crane

PK 44502 High Performance

A perfect combination of electronics and hydraulics allows high lifting power and Maximum profitability

  • Maximum utilisation of the working range thanks to HPSC
  • Additional applications with Power Link Plus
  • Shorter load cycle times thanks to High Speed Extention
  • High value retention thanks to coating technology
  • High operator friendliness thanks to radio remote control

Low-maintenance extension system

With sliding elements made of synthetic material and the high-quality KTL coating, this boom system significantly simplifies service performed by the operator. This saves time and money – and protects the environment.

Power Link Plus

The PALFINGER Power Link Plus system is a double linkage system with a linkage on the knuckle boom and a linkage between the main boom and crane column. With the 15 degree reverse linkage system, reaching through low door openings or working inside buildings is no problem.

Details

High Speed Extension

The High Speed Extension is a standard feature on PALFINGER loader cranes. Also referred to as Return Oil Utilization, this feature is a regenerative hydraulic circuit for the extension booms. It speeds up the boom extend and retract functions by up to 30%.

Downloads

Brochures

PK 44502 | 48002 EH

2,79 MB Download
