Medium

PK 36502 High Performance

Loader Crane

PK 36502 High Performance

Powerful performance with low dead weight and high efficiency.

  • High value retention thanks to coating technology
  • Additional applications due to Power Link Plus
  • Maximum utilisation of the working range due to HPSC
  • Shorter load cycle times due to High Speed Extention

Low-maintenance extension system

With sliding elements made of synthetic material and the high-quality KTL coating, this boom system significantly simplifies service performed by the operator. This saves time and money – and protects the environment.

Power Link Plus

The PALFINGER Power Link Plus system is a double linkage system with a linkage on the knuckle boom and a linkage between the main boom and crane column. With the 15 degree reverse linkage system, reaching through low door openings or working inside buildings is no problem.

Details

High Speed Extension

The High Speed Extension is a standard feature on PALFINGER loader cranes. Also referred to as Return Oil Utilization, this feature is a regenerative hydraulic circuit for the extension booms. It speeds up the boom extend and retract functions by up to 30%.

Downloads

Brochures

PK 36502 | 41002 EH

3,43 MB Download
