Medium

PK 12002 EH High Performance

Loader Crane

PK 12002 EH High Performance

The compact design and Power Link Plus are attribues for efficiency and cost effectiveness

  • Maximum precision and safety due to optional AOS
  • High value retention thanks to coating technology
  • Maximum reliability due to PAL 50
  • High operator friendliness thanks to optional radio remote control
  • Additional applications with Power Link Plus

eDRIVE

With the intelligent eDRIVE system, absolute flexibility in operating a loader crane is ensured: Via the Li-ion battery pack, a power grid or via the integrated generator which operates from the vehicle engine, and regenerates the Li-ion battery pack.

Details

High Power Lifting System

The PALFINGER High Power Lifting System (E-HPLS, A-HPLS or S-HPLS) increases the capacity of the crane by up to 15% while reducing working speed. E-HPLS can be activated manually for the occasional manipulation of very heavy loads. A-HPLS as well as S-HPLS are activated fully automatically. There is continuous activation depending on the power required.

Details

Low-maintenance extension system

With sliding elements made of synthetic material and the high-quality KTL coating, this boom system significantly simplifies service performed by the operator. This saves time and money – and protects the environment.

Power Link Plus

The PALFINGER Power Link Plus system is a double linkage system with a linkage on the knuckle boom and a linkage between the main boom and crane column. With the 15 degree reverse linkage system, reaching through low door openings or working inside buildings is no problem.

Details

High Speed Extension

The High Speed Extension is a standard feature on PALFINGER loader cranes. Also referred to as Return Oil Utilization, this feature is a regenerative hydraulic circuit for the extension booms. It speeds up the boom extend and retract functions by up to 30%.

Downloads

Brochures

PK 11002 / 12002 EH

2,06 MB Download
