4-WAY
GLS 55 4W
Truck Mounted Forklift
GLS 55 4W
| Capacity @ 24'' Load center | 5500 lbs |
| Horsepower | 56 hp |
| Engine | Diesel |
| Engine emission compliance EPA | TIER 4 Final |
| Maximum engine RPM | 2700 rpm |
| Electrical system | 12 Volt |
| Drive wheels | 3 |
| Steering | Hydrostatic |
| Tire type: Front: Tractor grip | Skid steer | 31x13-16.5 10 PLY |
| Tire type: Rear: Tractor grip | Skid steer | 31x15.5-15 12 PLY |
| Tire outside diameter | 31.5"/ 31" |
| Tire width | 13'' / 15 1/2" |
| Maximum speed | 7 mph |
| Maximum gradability | 30% (4 Way Mode 15%) |
| Turning radius | 76" |
| Unladen weight | 7005 lbs I 7120 lbs |
| Working pressure for attachments | 3000 PSI |
| Tilt of mast (Forward / Back) | 10⁰/ 8⁰ |
| Sideshift | 6" |
| Fork section: Lumber | 48" x 6" x 2" |
| Mast Carriage Travel | 31" |
| Counter Weights | No |
| Height to top of canopy | 101" |
| Fork carriage width | Fork boards | 47 1/4" I CLASS III at Class IV Spread |
| Frame opening | 58" |
| Overall width | 101 1/2" / 101" |
| Overhang | 60" |
| Wheel base | 65 1/2" |
| C. OF. G. from Forkface | 18 3/4" |
| Lift height | 120" I 144" |
| Mast height collapsed | 88 3/4" I 100 3/4" |
| Mast height raised | 148 3/4" I 172 3/4" |
| Ground clearance | 11" |
| Face of fork to center of Front tire | 15" |
| Ansi standard | B56.14 |
