up to 43,000 ft lbs
PAL Pro 43
Mechanics Trucks
Built for powerful cranes
PAL Pro 43 is manufactured using 12-gauge A-60 galvanneal steel and features a full-length hybrid torsion box understructure that eliminates frame and side pack deflection. Combined with integrated outrigger housings that transfer crane load directly to the ground, PAL Pro 43 effectively manages crane forces while preventing flexing and cracking.
PAL Pro 43 features a 43,000 ft. lbs. crane reinforcement designed to accommodate PALFINGER PSC 3216, 4016, 4025, 5025, 6025, and 8029 service cranes.
Optimized for increased payload
PAL Pro 43 is designed to be light-weight without sacrificing durability. Tubular 3”x 5” structural steel crossmembers interlaced into the body's understructure and internal gussets on every raised compartment provide a rigid body for storage of equipment, tools, and accessories.
Ready for top mounted accessories
Threaded weldment options available from the factory make installing top mounted accessories easy. Boom rest, welder, compressor, EnPak, Air-n-Arc and AirPak mounts eliminate the need to drill holes in the body.
Light-weight aluminum doors & trays
PAL Pro 43 features light-weight aluminum double panel doors that provide rigid performance with internal C-channel stiffeners adhered with structural adhesive. Interior compartments feature aluminum hinges and divider trays that are light-weight and corrosion resistant.
Zolatone interior compartment coating
Interior compartments on the PAL Pro 43 are coated with Zolatone to resist damage commonly caused by tools, chains, and parts. Zolatone provides an additional layer of rust protection and as an added bonus, the coating is white in color and helps to brighten up the interior.
A true mechanics work bench
PAL Pro 43 features either a 12" or 21" deep work bench bumper designed to provide technicians with a useable work surface for field repairs, welding, and more. Each bumper features a 1/4" steel top plate and the 21" bumper adds a thru-compartment for internal storage of long tools and chains.
Integrated hitch receiver
All PAL Pro 43 bumpers come standard with a 2" class 5 receiver tube hitch rated for 16,000 lbs. of towing capacity.
- 44" standard compartment heights with raised compartment options
- 11' standard configurations
- Treadplate cargo floor, load space walls and compartment tops
- Hybrid torsion box and ladder frame
- PALFINGER engineered internal gussets prevents body cracking
- Full length channel drip rails
- Double panel doors with internal C-channel stiffeners, adhered with structural adhesive
- Non-marring boom rest
- Work bench featuring 12" or 21" bumper, 1/4" steel top plate, and receiver hitch
- Linear adjustable front mounts
- Aluminium doors and hinges
- A-60 galvanealed zinc coated steel
- Rubber mounted LED lights
- E-coat primer
- Fixed or adjustable non-marring boom support (E-Coated)
- Threaded weldment options for installing boom rest, welders, compressors, etc.
- Stabilizer options include power or manual extend configurations
- Aluminum divider trays
- Aluminum roll-out drawers
- Bolt on handrail for added safety
- Master lock system
- Low sliding roof
- Headache rack with light bar mount
- Aluminum rock guards
- LED compartment lighting
- LED work lighting
- Air compressor hose reel and FLR
- Standard and metallic top coat paint
- And much more.....
