7 - 17 t GVW
TELESCOPIC T7S
from 7 to 10 t GVW trucks
Hooklift
Key Specs
- Max. loading capacity
- 5 t/7 t
- Unit length
- 3155 - 4055 mm
- Container length
- 2500 - 4750 mm
The T 05 PLUS Telescopic hooklifts deliver high versatility with a proven sliding system that accommodates different container lengths and adapts easily to various market needs. Their low transport height and reduced weight provide safe, flexible solutions for a wide range of applications worldwide.
Technical Specifications
Technical data
| Product Type | Lifting Capacity (t) | Dead Weight (kg) | Truck GVW (t) | Hook Height (mm) | Length (mm) | Container Length (max) | Container Length Min (mm) | Tipping Angle (°) | Pump Flow (l/min) | Pressure Setting (bar) |
| T7 S_L3155 | 7 | 78 | 9.5-12 | 900/920 | 3155 | 3800 | 2500 | 48 | 40-65 | 205 |
| T7 S_L3400 | 7 | 810 | 9.5-12 | 900/920 | 2400 | 4000 | 2750 | 46 | 40-65 | 210 |
| T7 S_L3605 | 7 | 830 | 9.5-12 | 900/920 | 3605 | 4250 | 2800 | 49 | 40-65 | 200 |
| T7 S_L3805 | 7 | 850 | 9.5-12 | 900/920 | 2805 | 4500 | 2950 | 49 | 40-65 | 225 |
| T7 S_L4055 | 7 | 900 | 9.5-12 | 900/920 | 4055 | 4750 | 3250 | 45 | 40-65 | 235 |
