18 - 19 t GVW

POWER P17

for 26 t GVW trucks

alt text
Hooklift
Key Specs
Max. loading capacity
17 t
Unit length
4750 - 5950 mm
Container length
4750 - 7000 mm

Designed for the harshest work, it will never let you down providing unwavering performance in demanding and off-road environments. Its robust design delivers full lifting power even when conditions are difficult, loads exceed expectations, or containers are stuck in ditches. When reliability matters most, this system is engineered to keep working.

Find Sales Partner

Request a quote

I agree that PALFINGER may process and store my data submitted above and forward it to the responsible sales and service partner to respond to my inquiry.

I agree that PALFINGER may store my data beyond this inquiry and send me further information, highlights and offers for marketing purposes via newsletter.

Request a quote

I agree that PALFINGER may process and store my data submitted above and forward it to the responsible sales and service partner to respond to my inquiry.

I agree that PALFINGER may store my data beyond this inquiry and send me further information, highlights and offers for marketing purposes via newsletter.

Designed for tough applications

POWER hookloaders deliver exceptional strength and reliability for the most demanding jobs. Their smart rotational design ensures smooth, controlled movements and full lifting power at any height. Built for harsh conditions, they can free stuck containers with ease and keep operations running smoothly.

Power that never fades

Power range hookloaders deliver exceptional strength for demanding lifting tasks, including retrieving containers from deep pits. Their advanced design maintains full lifting capacity at any frame height, avoiding performance loss in difficult positions. Rotational movement ensures smoother operation, reducing stress on components and increasing overall durability.

Built for harsh environments, Power units perform reliably in construction and agricultural settings where mud, ice, or uneven ground can cause containers to stick. Their strong pulling force enables dependable extraction and steady operation, even under extreme conditions. When maximum strength and durability are required, the Power range is the definitive choice.
alt text

Minimal maintenance and reduced wearing

The kinematic design ensures the system never operates at its limits, helping preserve components over time. Its force-triangle layout reduces pressure on hydraulic parts, minimizing wear and extending service life. Cast components—including the hook, rear pivot, hinge supports, and rear pulleys—add durability and long-lasting robustness.

alt text

Equipment & Accessories

Under-Ride Protection

The PALFINGER rear under-ride protection, compliant with R58-03, is engineered for easy installation and is fully compatible with N3 trucks.
alt text

Routing

Pre-fitted pipes on the rear left of the equipment provide ready-to-use hydraulic lines for additional functions. These lines allow new hydraulic features to be connected directly to the couplings, making installation faster and easier.
alt text

Crane Interface

The reinforced subframe makes it easy to install a crane while providing strong, reliable support for heavy lifting. Because no welding is needed on the hookloader, installation is simpler, and the overall setup is safer and more efficient for material handling.
alt text

Technical Specifications

Technical data

P 17

Market standards : NF - DIN

Hookheight (mm) : 1425-1570

Length (mm) : 4600-4750-4900-5100-5300-5450-5600-5750-5950

Container min. length : 4500 mm

Container max. length : 7000 mm

Rail width : 1060 mm

GVW truck : 26 t

Average weight : 2100 kg

Transport height : 240 mm

Tipping angle : 45-52°

Technical data
Unit length (mm)Container max. length (mm)Container min. length (mm))Transport heightWeight (kg)Tipping angle (°)
460056004500240195052
475058004750240195049
490060004750240200047
510062005000240205050
530064005250240210050
545066005400240215048
560068005500240220046
575068005750240225048
595070006000240225048

Optional Features

alt text

E-pto control via canbus

Reduced energy consumption through on-demand pump control and optimized oil flow for hookloaders installed on e-trucks.


alt text

Silent mode

Flashing lights replace the traditional buzzer to reduce noise without compromising safety. Perfect for night urban environments and e-truck applications.


alt text

System monitoring

Enhanced operational safety with an in-cab screen and three cameras that monitor the system and its surroundings, including a view-tracking function.


alt text

Soft sliding

The bolted anti-friction container rest in reinforced polyamide enables smooth, quiet loading, improving the working environment for the operator and the surrounding area. The bolted design also allows quick, easy replacement when required.
