Smart Class
P 200 A
P 200 A
Aerial Work Platform
Key Specs
- Working Height
- 19.8 m
- Basket Load
- 230 kg
- Side Reach
- 8.4 m
Thanks to its compact structure with a short wheelbase, the P 200 A smart is particularly suitable for use in city centres. Wherever there is insufficient space to position the vehicle, the advantages of the small, clever truck access platform become patently clear. The joint/telescope combination allows for amazingly flexible height access. Easy operation, ergonomic design, fully hydraulic processes and professional Palfinger quality ensure safety for working at height and provide outstanding guarantees for jobs in the field performed high up.
Technical Specifications
Technical data
- Max. height of work
- 19.8 m
- Max. basket floor height
- 17.8 m
- Max. horizontal outreach /with basket load
- 8.4 m
- Max. basket load
- 230 kg
- Workman basket - breadth / length / height
- 1.4 x 0.85 x 1.1 m
- Angle of main boom
- -25° - +80°
- Rotation angle of turntable
- 370°
- Height in transport position
- 2.89 m
- Width in transport position
- 2.1 m
- Length in transport position
- 5.39 m
- Overall weight
- 3,320 kg
*above mentioned values are standard values and vary depending on options and chassis
Units shown are partially optional equipped and do not always correspond to the standard version.
Country-specific regulations must be observed. Dimensions may vary. Subject to technical changes, errors and translation mistakes.
