Heavy

PK 62002 EH High Performance

PK 62002 EH High Performance

Loader Crane

Robust heavy duty crane technology and mature electronics are guarantors for long-life cyclerobust heavy duty crane technology

  • Maximum utilisation of the working range thanks to HPSC
  • High operator friendliness thanks to radio remote control
  • Additional applications with Power Link Plus
  • Shorter load cycle times thanks to High Speed Extention
  • High value retention due to coating technology

High Power Lifting System

The PALFINGER High Power Lifting System (E-HPLS, A-HPLS or S-HPLS) increases the capacity of the crane by up to 15% while reducing working speed. E-HPLS can be activated manually for the occasional manipulation of very heavy loads. A-HPLS as well as S-HPLS are activated fully automatically. There is continuous activation depending on the power required.

Details

Low-maintenance extension system

With sliding elements made of synthetic material and the high-quality KTL coating, this boom system significantly simplifies service performed by the operator. This saves time and money – and protects the environment.

Power Link Plus

The PALFINGER Power Link Plus system is a double linkage system with a linkage on the knuckle boom and a linkage between the main boom and crane column. With the 15 degree reverse linkage system, reaching through low door openings or working inside buildings is no problem.

Details

High Speed Extension

The High Speed Extension is a standard feature on PALFINGER loader cranes. Also referred to as Return Oil Utilization, this feature is a regenerative hydraulic circuit for the extension booms. It speeds up the boom extend and retract functions by up to 30%.

Downloads

Brochures

PK 56502 / PK 62002 EH

1,69 MB Download

CRANE TOOLS

26,88 MB Download
