Light

PK 7.001K SLD 3

alt text
Loader Crane
Key Specs
Max. lifting moment
6.2 mt
Max. lifting capacity
3,300 kg
Max. hydraulic outreach
8.8 m

The SLD range combines trusted technology with durable design to deliver robust, value-driven performance. The PK 7.001K SLD 3 is a highly versatile crane for wide-ranging municipal tasks in challenging settings, such as near structures and traffic. High Speed Extension accelerates telescoping for rapid roadside operations.

Find Sales Partner

Request a quote

I agree that PALFINGER may process and store my data submitted above and forward it to the responsible sales and service partner to respond to my inquiry.

I agree that PALFINGER may store my data beyond this inquiry and send me further information, highlights and offers for marketing purposes via newsletter.

Request a quote

I agree that PALFINGER may process and store my data submitted above and forward it to the responsible sales and service partner to respond to my inquiry.

I agree that PALFINGER may store my data beyond this inquiry and send me further information, highlights and offers for marketing purposes via newsletter.

Diagrams

PK 7.001K SLD ()

View
alt text

PK 7.001K SLD A

View
alt text

PK 7.001K SLD B

View
alt text

Technical Specifications

alt text
Technical data
Max. lifting moment
6.2 mt
Max. lifting capacity
3,300 kg
Max. hydraulic outreach
8.8 m
Max. manual outreach
12.4 m
Slewing angle
400°
Slewing torque with 1 gear
0.8 mt
Stabilizer spread (std)
3.0 m
Fitting space required (std)
0.66 m
Width folded
2.2 m
Max. operating pressure
330 bar
Pump capacity
30 l/min
Dead weight (std)
735 kg

Cranes shown in the leaflet are partially optional equipped and do not always correspond to the standard version.
Country-specific regulations must be observed. Dimensions may vary. Subject to technical changes, errors and translation mistakes.

Lifting capacities

Crane Height (mm)

Crane Weight (kg)

Crane Width (mm)

Installation Width (mm)

Lifting moment (mt)

Outreach (m)

Pressure (MPa)

Pump capacity (l/min)

Slewing angle (°)

Slewing torque (mt)
Std 1,930 mm 735 kg 2,200 mm 660 mm 6.2 mt 5 m 33 Mpa 30 400 0.8
A 1,930 mm 815 kg 2,200 mm 660 mm 6 mt 6.9 m 33 Mpa 30 400 0.8
B 1,930 mm 885 kg 2,200 mm 660 mm 5.8 mt 8.8 m 33 Mpa 30 400 0.8
alt text

The outreaches stated are with a boom angle of 20° and are therefore not the maximum. When using mechanical boom extensions, the loads shown on the charts need to be reduced by the weight of these extensions.
