V 1000 - 1500 SCL/SML
The specified weights apply to the lightest platforms of the corresponding height. Dimensions may vary. Subject to technical changes, errors and translation mistakes.
|Q Traglast (kg)||1000||1500|
|a load distance (mm)||1000||1000|
|A lifting height||3864 mm|
|B lifting width||2543 mm|
|H1 height of deck 1||1900 mm|
|H2 height of deck 2||1798 mm|
|X platform height||2771 mm|
|Y height of bridging plate (as platform extension Y-80)|
|Maximum loading-space width||1990 mm|
|Maximum loading-space height||1798 mm|
