Smart Class
P 140 T
P 140 T
Access Platform
| Max. height of work | 13.5 m |
| Max. basket floor height | 11.5 m |
| Max. horizontal outreach /with basket load | 8.4 |
| Slewing range of basket | 2 x 90° |
| max. basket load | 230 kg |
| Workman basket - breadth / length / height | 1.4 x 0.85 x 1.1 m |
| Height in transport position | 2.89 m |
| Width in transport position | 2.10 m |
| Overall length | 6.05 m |
| Overall weight | 3200 kg |
*above mentioned values are standard values and vary depending on options and chassis
Units shown are partially optional equipped and do not always correspond to the standard version.
Country-specific regulations must be observed. Dimensions may vary. Subject to technical changes, errors and translation mistakes.
A possible 2% tolerance is contingent on structural components depending on chassis and equipment
