Low Smart Class
P 130 A
P 130 A
| Max. height of work | 42.65 ft |
| Max. basket floor height | 36.09 ft |
| Max. horizontal outreach /with basket load | 20.67 ft |
| max. basket load | 551.16 lbs |
| Workman basket - breadth / length / height | 4.59 x 2.29 x 3.61 ft |
| Angle of main boom | -20° +80° |
| Rotation angle of turntable | 360° |
| Height in transport position | 7.38 ft |
| Width in transport position | 6.17 ft |
| Length in transport position | 18.21 ft |
*above mentioned values are standard values and vary depending on options and chassis
Units shown are partially optional equipped and do not always correspond to the standard version.
Country-specific regulations must be observed. Dimensions may vary. Subject to technical changes, errors and translation mistakes.
*above mentioned values are standard values and vary depending on options and chassis
Units shown are partially optional equipped and do not always correspond to the standard version.
Country-specific regulations must be observed. Dimensions may vary. Subject to technical changes, errors and translation mistakes.
| Max. height of work | 13 m |
| Max. basket floor height | 11 m |
| Max. horizontal outreach /with basket load | 6,3 м. |
| max. basket load | 250 kg |
| Workman basket - breadth / length / height | 1,4 х 0,7 х 1,1 м. |
| Angle of main boom | -20° +80° |
| Rotation angle of turntable | 360° |
| Height in transport position | 2.37 m |
| Width in transport position | 1.88 m |
*above mentioned values are standard values and vary depending on options and chassis
Units shown are partially optional equipped and do not always correspond to the standard version.
Country-specific regulations must be observed. Dimensions may vary. Subject to technical changes, errors and translation mistakes.
