Medium
PK 15500
Loader Crane
Key Specs
- Max. lifting moment
- 14.4 mt
- Max. lifting capacity
- 6,200 kg
- Max. hydraulic outreach
- 14.6 m
Our Performance cranes are engineered to handle building materials securely, offering high lifting capacity and convenient control. The PK 15500 handles both light machinery and heavy loads with consistent precision and speed. High Speed Extension enables swift boom movements, ideal for efficient work in industrial environments.
Technical Specifications
Technical data
- Max. lifting moment
- 14.4 mt
- Max. lifting capacity
- 6,200 kg
- Max. hydraulic outreach
- 14.6 m
- Max. outreach (with fly jib)
- 18.8 m
- Slewing angle
- 420°
- Slewing torque
- 1.8 mt
- Stabilizer spread (std)
- 4.6 m
- Fitting space required (std)
- 0.81 m
- Width folded
- 2.5 m
- Max. operating pressure
- 300 bar
- Pump capacity
- 40 - 60 l/min
- Dead weight (std)
- 1,619 kg
Cranes shown in the leaflet are partially optional equipped and do not always correspond to the standard version.
Country-specific regulations must be observed. Dimensions may vary. Subject to technical changes, errors and translation mistakes.
Lifting capacities
|
Crane Height (mm) |
Crane Weight (kg) |
Crane Width (mm) |
Installation Width (mm) |
Lifting moment (mt) |
Outreach (m) |
Pressure (MPa) |
Pump capacity (l/min) |
Slewing angle (°) |
Slewing torque (mt) |
|
|---|---|---|---|---|---|---|---|---|---|---|
| Std | 2,200 mm | 1,619 kg | 2,500 mm | 810 mm | 14.6 mt | 6.2 m | 30 Mpa | 40 - 60 | 420 | 1.8 |
| A | 2,200 mm | 1,769 kg | 2,500 mm | 810 mm | 14.1 mt | 8.1 m | 30 Mpa | 40-60 | 420 | 1.8 |
| B | 2,200 mm | 1,904 kg | 2,500 mm | 810 mm | 13.7 mt | 10.3 m | 30 Mpa | 40-60 | 420 | 1.8 |
| C | 2,200 mm | 2,029 kg | 2,500 mm | 810 mm | 13.2 mt | 12.4 m | 30 Mpa | 40-60 | 420 | 1.8 |
| D | 2,200 mm | 2,170 kg | 2,500 mm | 920 mm | 12.8 mt | 14.5 m | 30 Mpa | 40-60 | 420 | 1.8 |
Cranes shown in the leaflet are partially optional equipped and do not always correspond to the standard version.
Country-specific regulations must be observed. Dimensions may vary. Subject to technical changes, errors and translation mistakes.
High Speed Extension – Faster Cycles
High Speed Extension increases boom extension and retraction speed by up to 30% by reusing return oil within the hydraulic system. Faster movements reduce load cycle times and improve overall productivity. The crane completes more work in less time without compromising control or precision.
Long-Lasting Coating for Maximum Protection
Advanced coating technology protects components against corrosion, wear, and harsh weather conditions. Multi-stage surface treatment and durable, eco-friendly coatings create a tough, elastic finish with high impact and UV resistance. This extends service life, maintains a high-quality appearance, and preserves resale value while reducing environmental impact and long-term maintenance effort.
Optional Features
Radio Remote Control – Full Control
Radio remote control system operates the crane safely and efficiently from a distance. Operator commands are transmitted wirelessly delivering precise hydraulic movements. This enables clear visibility of the load, one-person operation, and allows work outside danger zones. Adjustable controls, speed settings, and built-in safety shutoffs improve comfort, accuracy, and overall job site safety.
PALTRONIC – Smart Crane Control
PALTRONIC control electronics continuously monitor crane load, position, and stability in real time. Sensors send data to the system, which automatically activates safety, assistance, and performance functions when needed. This results in smoother movements, overload protection, improved stability, and easier operation—allowing the operator to focus fully on safe, precise load handling.
