Renault

PK100002 E

Contract number: 2000110720
  • new
  • On request

Specification

PK100 002 Extension E

Max. lifting moment                                92.2 mt / 904.5 kNm



Max. lifting capacity

30000 kg/ 294.3 kN

66140 lbs

Max. hydraulic outreach

22.0 m

72’ 2”

Max. manual outreach

27.1 m

88’ 11”

Max. outreach (with fly-jib)

32.0 m

104’ 12”

Slewing angle

continuously variable



Slewing torque

9.0 mt/ 88.3 kNm

65100 ft.lbs

Stabiliser spread (std.)

8.6 m

28’ 3”

Fitting space required (std.)

2.31 m / 2.47 m

7’ 7”/ 8’ 1”

Width folded                                            2.55 m                               8’ 4”

Max. operating pressure

365 bar

5293 psi

Recommended pump capacity

from 90 l/min

to 110 l/min

23.8 US gal./min

29.1 US gal./min

Dead weight (std.)                                   8800 kg                             19400 lbs

Offer

KPPK100002M4EN.pdf
2.20 MB
Download

Offer information

Location details
Köstendorf, 5203 - Austria
Dealer details
PALFINGER EMEA GmbH
Dealer E-mail
l.meskine-rodriguez@palfinger.com
m.butler@palfinger.com
Dealer phone
00436648343115
Availability
On request
Product type
new
Contract number
2000110720

Truck

Axes 8x4
Emission Euro 3

Attachment

Lifiting Capacity

LIFTING CAPACITY.pdf
0.62 MB
Download

Brochure

KPPK100002M4EN.pdf
2.20 MB
Download

Brochure

KPPK100002M4FR.pdf
2.21 MB
Download
