PK 580 TEC
Scania R 590 B8x4NB
Contract number: Paldrive 632
Specification
PK 580 TEC
| lifting moment | 55,5 mt |
| slewing angle | continous |
| Max. outreach | 31,4 m |
MCC-INSTALLATION
| Flatbed | |
|---|---|
| Platform length | 4100 mm |
| Platform width | 2480 mm |
| Frontwall height | 1200 mm |
| Side- and rearwall height | 400 mm |
| fifth wheel height | 1310 mm |
SCANIA R590 B8x4NB
| engine power | 590 HP |
| wheelbase | 1990/ 2560/1350 mm |
| cabin | CR20N |
| gearbox | G33CM incl. Opticruise |
Offer information
Location details
MCC-NORTH SOLEC, 86-050 - Poland
Dealer Name
Palfinger EMEA GmbH AT
Product type
New Contract number
Paldrive 632 Product
| Manufacturer | Palfinger |
|---|---|
| Model | PK 580 TEC + PJ150 |
| Lifting moment | 55,5 mt |
|---|---|
| Outreach / Lifting power | 31,4 m / 390 kg |
| Max outreach | 31,4 m |
truck
| Truck manufacturer | Scania |
|---|---|
| Drivers cabine | CR20N |
| Wheel base | 1990 + 2560 + 1350 mm |
| Power | 590 PS |
| Emmission standard | EURO 6e |
| Axes | 8x4 |
|---|---|
| Gross vehicle weight | 32.000 Kg |
| Dead weight | 23.200 kg |
| Payload | 8.800 kg |
| Payload category | 6t - 15t |
| Construction | Heavy duty crane |
PK 580TEC
HYDRAULIC & TECHNICS
- Hydraulic 7-fold extension
- High-speed extension system with return oil recovery
- Endless swivel range
- Hydraulic support leg extension (max.support width 7.800 mm)
- Additional hydraulic support (max.support width 4.400 mm)
- Support legs can be swiveled hydraulically through 180 °
- 1x additional front stabilizer
ASSISTANCE SYSTEMS
- Paltronic 180
- HPSC Plus LOAD
- P-FOLD
- PALcom P7 radio remote control
EQUIPMENT
- Working lights on the articulated arm and on the fly jib (PJ150-E)
- Hose equipment for two additional devices
- 3.5t rope winch on the main arm (can be folded down hydr.), Cable length: 90m
- Automatic rope tensioning device (RTC) and rope winch synchronous control (SRC)
- Preparation for workman basket operation EN280
- 11,5 to load hook
- Painting RAL3020
PJ150-E (additional knuckle arm)
- Hydraulic 6-fold extension
- Can be folded upwards by 25 ° hydraulically
- Preparation for workman basket operation
Scania R 590 B8x4NB
SPECIFICATIONS
- 590 HP, max. 3.050 Nm
- Gearbox G33CM incl. Opticruise
- Suspension Air/ Air
- Fuel tank 355l / AD-Blue 47l
- Tires 385/65 R22.5
- Tires on driven axle 315/ 80R22.5
- Cabin color: Ivory White
- Chassis color: Sub Grey
- towbar type VBG 795VR-3 S/S
Service crane technical details
