PK 135.002 TEC7
MAN TGS 35.540 8x2H-6 BL CH
Contract number: Paldrive 539
Specification
All images are from a reference project
PK 135.002 TEC7
| lifting moment | 109,3 mt |
| max. outreach incl. Fly-Jib | 32,0 m |
| max. lifting capacity | 30.000 Kg |
| swivel range | endless |
| rope whinch type | 3,5to |
MCC-INSTALLATION
| low built Platform | |
|---|---|
| Platform length | 4.100 mm |
| Platform width | 2.480 mm |
| frontwall height | 1.400 mm |
| side & rearwall height | 600 mm |
| loading height | 1.200 mm |
| Platform floor | 27mm Aluminium |
MAN TGS 35.540 8x2H-6 BL CH
| construction year | 2025 |
| power | 540 Hp |
| gearbox | MAN TipMatic 12.28 OD |
| main Wheelbase | 4.775 mm |
| cabin | TM |
| GSR II options | yes |
Offer information
Location details
MAN Trucks & BUS SE, 80995 - Germany
Dealer Name
Palfinger EMEA GmbH PL
Availability
Available
Product type
New Contract number
Paldrive 539 Product
| Manufacturer | Palfinger |
|---|---|
| Model | PK 135.002 TEC7 |
| Construction year | 2024 |
| Lifting moment | 109,3 mt |
|---|---|
| Outreach / Lifting power | 32,0 m / 1.280 kg |
truck
| Truck manufacturer | MAN |
|---|---|
| Construction year | 2025 |
| Drivers cabine | TM |
| Wheel base | 1.795 mm + 2.980 mm + 1.350 mm |
| Power | 540 PS |
| Emmission standard | EURO 6 |
| Axes | 8x2*6 |
|---|---|
| Gross vehicle weight | 32.000 kg |
| Dead weight | 29.900 kg |
| Payload | 2.100 kg |
| Payload category | <6t |
| Construction | Heavy duty crane |
PK 135.002 TEC7
HYDRAULIC & TECHNICS
- 8 hydraulic boom extensions (G)
- High-speed boom extension system with return oil recovery
- Swivel range endless
- Hydraulic support leg extension (max.support width 10.000mm)
- Support legs can be swiveled hydraulically through 180°
- Additional hydraulic support (support width ca. 8.500 mm)
- Hose equipment for two additional devices including quick coupling (multi-faster)
- 3,5to cable winch on the main arm (hydr. foldable)
- Rope length: 90m
ASSISTANCE SYSTEMS
- Paltronic 150
- HPSC + LOAD
- Remote controlled stabilizers
- CPS (cabin protection)
- FPS (Frame Protection System)
- P-FOLD (Folding Assistant)
- AOS (Active Oscillation Suppression)
- SRC (Synchronised Rope Control)
- RTC (Rope Tension Control)
EQUIPMENT
- Palcom P7 radio remote control /9 functions with cross levers
- Working light on the articulated arm
- 11,5to & 18,0to load hook
- 2 strand rope equipment on the Crane
- Painting RAL3020
- hydraulic oil tank 400 l
PJ 190 E
Configuration
- 6 hydraulic extensions (E)
- High-speed extension system with return oil recovery
- Hydr. tiltable upwards by 25°
- MFA-L - Multifunctional adapter
- 1 strand rope equipment for the PJ 190
- Working light at the PJ 190
- Hose equipment for two additional devices including quick coupling (multi-faster)
PJM020
Configuration
- Manual jib to increase reach
- 2 manual extensions
- Manual Angle Adjustment (+ 20° / 0° / -20° / -40° / -60°)
- Max. outreach 5.25 m
- Max. load 650 kg
- Painting RAL7021
- 1 strand rope equipment for the PJM020
- SRC (Synchronised Rope Control)
Installation
- Palfinger MCC low build platform
- Platform inner dimenstions: 4.100mm x 2.480mm
- Front wall: height 1.400 mm including a toolbox, 4 working lights & retaining bar for chains and loops
- Side- and rearwalls height: 600 mm
- Platform floor 27 mm Aluminium
- Loading height: 1.200mm
- 8 working lights (4x at stabilizers & 4x at frontwall)
- 4 reversing lights
- Rear view camera
- Emergency power pack for basket operation
- Heavy duty tool box with a load capacity of 500 kg
- 2 pcs. of heavy duty chain-trays at the additional stabilizers
- Trailer coupling: ROCKINGER Typ 400 G 150A
- 2 wheel chocks
MAN TGS 35.540 8x2H-6 BL CH
- Engine: 540 Hp, torque max. 2.650 Nm
- Gearbox: MAN TipMatic 12.28 OD + MAN pritarder
- Axle distance: 1.795mm + 2.980mm + 1.350mm
- leaf suspension on front axles / leaf suspension on rear axles
- Fuel tank 390l / AD-Blue 35l
- Tires 1st, 2nd & 4th axle: 385/65R22.5
- Tires driven axle: 315/80 R22.5
- Rims on all axles: aluminium Alcoa Durabright
- Cabin colour: RAL 9016 / chassis colour: RAL9011
- Cabin type: TM
- Premium Cabin interior
- auxiliary heating: 4 kW
- Multifunctional steering wheel
- Infotainment system equipped with 12,3-inch colour display
- GSR II options included
- construction Year: 2025
