PK 24.001 SLD 5

Specification

PK 24.001 SLD 5

- Hydraulic 5-fold extension

- High-speed extension system with return oil recovery

- Swivel range 400^o

- Hydraulic support leg extension (max.support width 7.400mm)

- Rigid support legs + support leg extension 100mm

- Paltronic 40

- HPSC-E

- Sanreco radio remote control (2-2-2 cross lever)

- Painting RAL3020

- Working lights on the articulated arm

- Hose equipment for two additional devices

- 8 t load hook

Platform

- L = 6,600mm and W = 2,480mm in the clear

- Usable front wall height 1,800mm inclusive two working lights

- Usable side wall height 950mm - Painted RAL9016 on both sides

- Side wall lifting aids + 2 folding steps per side wall

- Platform floor made of 27mm screen printing plates, impregnated and sealed

- platform profile 45° + lashing points every 250mm

MAN

- TGS 26.470 6x2-4 LL

- 470PS / 2400Nm

- Euro 6e

- TipMatic gearbox 12.26DD + retarder

- Air suspension on all axles

- Fuel tank 400l / AD-Blue 60l

- Tires 1st axle 385/65 R22.5

- Tires for drive and trailing axles 315/80 R22.5

- Cabin color: pure white RAL 9016 / chassis color: Graphite Black RAL9011

- Electric and compressed air hanger supply

- RINGFEDER trailer coupling type 4040 / G150B
