PK 12502 SH
Specification
PK 12502 SH
- Hydraulic 3-fold extension
- High-speed extension system with return oil recovery
- Swivel range 400o
- Hydraulic support leg extension (max.support width 4.900mm)
- Support leg extension 100mm
- Rigid support legs
- Paltronic 40
- HPSC-E + LOAD
- Sanreco radio remote control (2-2-2) cross lever
- Painting RAL3020
- Working lights on the articulated arm
- Hose equipment for two additional devices including quick coupling (multi-faster)
- 8.0t load hook
Tipper (MEILLER)
- MEILLER type 9
- 4,000 x 2,420 mm
- 800 mm height of the front wall of the tipping bridge
- 600 mm high side wall tipping bridge, steel
- Floor tipping bridge, made of steel HB 400, 4 mm
- Lashing eyes in the floor panel
- Rear wall of the tipping bridge, swinging and can be folded down to a certain extent, manual claw lock
MAN
- TGM 18.320 4x4 BB CH
- 320PS / 1.250Nm
- Leaf suspension 1st and 2nd axis
- Fuel tank 150l / AD-Blue 35l
- Tires 1st axle 315/80 R22.5
- Drive axle tires 315 / 80R22.5
- Cabin color: Traffic White RAL9016 / Chassis color: Graphite Black RAL9011
- Electric and compressed air hanger supply
- RINGFEDER trailer coupling type 4040 / G150B
